Kontynuując temat floty syjamskiej robimy dziś skok w czasie do lat 30-tych XX w. Okręt, który niżej prezentuję, to alternatywna, „napompowana” wersja pancerników obrony wybrzeża typu Sri Ayuthia. Te okręty w swojej oryginalnej postaci były dość kontrowersyjne, zwłaszcza wskutek mizernego opancerzenia, sięgającego zaledwie 63 mm na burcie, przez co niektórzy klasyfikowali je wręcz jako kanonierki. Mój okręt jest znacznie bardziej „rasowy” - ma uzbrojenie godne ciężkiego krążownika, ale na połowie jego wyporności i dysponuje konkretnym opancerzeniem (przy oczywiście umiarkowanej prędkości i niezbyt dużym zasięgu). Myślę, że takie jednostki, o ile byłyby kompetentnie wykorzystywane, stanowiły by np. dla floty francuskiej nie lada orzech do zgryzienia. Bitwa pod Ko Chang mogłaby wyglądać zgoła inaczej;)
Sri Ayuthia, siamese coast defence battleship laid down 1936 (Engine 1937)
Displacement:
4 506 t light; 4 809 t standard; 4 978 t normal; 5 114 t full load
Dimensions: Length overall / water x beam x draught
348,50 ft / 341,04 ft x 55,38 ft x 16,90 ft (normal load)
106,22 m / 103,95 m x 16,88 m x 5,15 m
Armament:
8 - 7,99" / 203 mm guns (4x2 guns), 255,24lbs / 115,77kg shells, 1920 Model
Breech loading guns in turrets (on barbettes)
on centreline ends, evenly spread, 2 raised mounts - superfiring
6 - 4,72" / 120 mm guns in single mounts, 52,72lbs / 23,91kg shells, 1921 Model
Dual purpose guns in deck mounts
on side, all amidships
6 - 1,57" / 40,0 mm guns in single mounts, 1,95lbs / 0,88kg shells, 1923 Model
Anti-aircraft guns in deck mounts
on side, all amidships, all raised mounts - superfiring
Weight of broadside 2 370 lbs / 1 075 kg
Shells per gun, main battery: 150
Armour:
- Belts: Width (max) Length (avg) Height (avg)
Main: 5,98" / 152 mm 118,50 ft / 36,12 m 12,50 ft / 3,81 m
Ends: Unarmoured
Main Belt covers 53% of normal length
Main belt does not fully cover magazines and engineering spaces
- Torpedo Bulkhead:
1,46" / 37 mm 118,50 ft / 36,12 m 15,94 ft / 4,86 m
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 7,01" / 178 mm 5,00" / 127 mm 7,01" / 178 mm
- Armour deck: 2,52" / 64 mm, Conning tower: 7,01" / 178 mm
Machinery:
Diesel Internal combustion motors,
Direct drive, 2 shafts, 11 285 shp / 8 419 Kw = 20,00 kts
Range 4 900nm at 10,00 kts
Bunker at max displacement = 305 tons
Complement:
296 - 385
Cost:
£2,375 million / $9,498 million
Distribution of weights at normal displacement:
Armament: 296 tons, 6,0%
Armour: 1 806 tons, 36,3%
- Belts: 463 tons, 9,3%
- Torpedo bulkhead: 102 tons, 2,0%
- Armament: 585 tons, 11,7%
- Armour Deck: 612 tons, 12,3%
- Conning Tower: 44 tons, 0,9%
Machinery: 313 tons, 6,3%
Hull, fittings & equipment: 2 091 tons, 42,0%
Fuel, ammunition & stores: 473 tons, 9,5%
Miscellaneous weights: 0 tons, 0,0%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
7 431 lbs / 3 371 Kg = 29,1 x 8,0 " / 203 mm shells or 2,1 torpedoes
Stability (Unstable if below 1.00): 1,01
Metacentric height 2,1 ft / 0,6 m
Roll period: 16,0 seconds
Steadiness - As gun platform (Average = 50 %): 52 %
- Recoil effect (Restricted arc if above 1.00): 0,76
Seaboat quality (Average = 1.00): 1,09
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,546
Length to Beam Ratio: 6,16 : 1
'Natural speed' for length: 18,47 kts
Power going to wave formation at top speed: 53 %
Trim (Max stability = 0, Max steadiness = 100): 48
Bow angle (Positive = bow angles forward): 17,00 degrees
Stern overhang: 1,51 ft / 0,46 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 19,46 ft / 5,93 m
- Forecastle (18%): 15,94 ft / 4,86 m
- Mid (54%): 16,96 ft / 5,17 m (9,48 ft / 2,89 m aft of break)
- Quarterdeck (14%): 9,48 ft / 2,89 m
- Stern: 10,01 ft / 3,05 m
- Average freeboard: 13,46 ft / 4,10 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 104,9%
- Above water (accommodation/working, high = better): 111,8%
Waterplane Area: 13 132 Square feet or 1 220 Square metres
Displacement factor (Displacement / loading): 104%
Structure weight / hull surface area: 110 lbs/sq ft or 539 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,92
- Longitudinal: 1,94
- Overall: 1,00
Hull space for machinery, storage, compartmentation is adequate
Room for accommodation and workspaces is adequate
Sri Ayuthia (1937)
Dhonburi (1938)
