Dziś kolejna jednostka będąca owocem dyskusji pod jednym z wcześniejszych postów. Jest to okręt wyposażony w 2 moździerze, przeznaczone do niszczenia fortyfikacji nadbrzeżnych, stworzony na bazie predrednota typu Kaiser Friedrich III. Głównym orężem jednostki są 2 ciężkie moździerze Gamma kal. 420 mm. Oprócz faktycznie dokonanych na okręcie zmian przed jego wycofaniem z linii w 1916 r. (likwidacja 4 kazamatowych dział 150 mm, wymiana masztów „kolumnowych” na lżejsze, palowe), dokonano następujących zmian: zlikwidowano wieże dział kal. 240 mm, zlikwidowano nadbudówkę na której spoczywała dziobowa wieża wraz ze znajdującymi się w niej kazamatami, zamontowano w miejscu wież 2 moździerze, zlikwidowano 4 działka 88 mm (na śródokręciu i nad stanowiskiem dowodzenia) a pozostałe wymieniono na nowsze o długości lufy 45 kal., przystosowane do strzelania przeciwlotniczego. Zlikwidowano też wszystkie podwodne wyrzutnie torped, zupełnie nieprzydatne w nowej roli okrętu.
Kaiser Barbarossa, german bombardment ship laid down 1898 (Engine 1900), rebuilt 1916
Displacement:
10 490 t light; 11 065 t standard; 11 605 t normal; 12 036 t full load
Dimensions: Length overall / water x beam x draught
410,99 ft / 410,99 ft x 66,99 ft x 27,07 ft (normal load)
125,27 m / 125,27 m x 20,42 m x 8,25 m
Armament:
2 - 16,54" / 420 mm guns in single mounts, 2 260,56lbs / 1 025,37kg shells, 1909 Model
Breech loading howitzers in open barbettes
on centreline ends, evenly spread
6 - 5,91" / 150 mm guns in single mounts, 102,98lbs / 46,71kg shells, 1897 Model
Quick firing guns in turrets (on barbettes)
on side, all amidships
6 - 5,91" / 150 mm guns in single mounts, 102,98lbs / 46,71kg shells, 1897 Model
Quick firing guns in casemate mounts
on side, evenly spread, 2 raised mounts
8 - 3,46" / 88,0 mm guns in single mounts, 20,79lbs / 9,43kg shells, 1915 Model
Anti-aircraft guns in deck mounts
on side, evenly spread, all raised mounts
Weight of broadside 5 923 lbs / 2 687 kg
Shells per gun, main battery: 100
Armour:
- Belts: Width (max) Length (avg) Height (avg)
Main: 11,8" / 300 mm 263,45 ft / 80,30 m 9,02 ft / 2,75 m
Ends: 5,91" / 150 mm 142,16 ft / 43,33 m 9,02 ft / 2,75 m
5,38 ft / 1,64 m Unarmoured ends
Main Belt covers 99% of normal length
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: - - 9,84" / 250 mm
2nd: 5,91" / 150 mm 2,76" / 70 mm 5,91" / 150 mm
3rd: 5,91" / 150 mm - -
4th: 1,57" / 40 mm - -
- Armour deck: 2,56" / 65 mm, Conning tower: 9,84" / 250 mm
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 3 shafts, 10 586 ihp / 7 897 Kw = 17,50 kts
Range 3 420nm at 10,00 kts
Bunker at max displacement = 971 tons (100% coal)
Complement:
558 - 726
Cost:
£1,221 million / $4,883 million
Distribution of weights at normal displacement:
Armament: 740 tons, 6,4%
Armour: 3 481 tons, 30,0%
- Belts: 1 513 tons, 13,0%
- Torpedo bulkhead: 0 tons, 0,0%
- Armament: 954 tons, 8,2%
- Armour Deck: 905 tons, 7,8%
- Conning Tower: 109 tons, 0,9%
Machinery: 1 654 tons, 14,3%
Hull, fittings & equipment: 4 614 tons, 39,8%
Fuel, ammunition & stores: 1 115 tons, 9,6%
Miscellaneous weights: 0 tons, 0,0%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
11 986 lbs / 5 437 Kg = 5,3 x 16,5 " / 420 mm shells or 1,7 torpedoes
Stability (Unstable if below 1.00): 1,16
Metacentric height 3,6 ft / 1,1 m
Roll period: 14,8 seconds
Steadiness - As gun platform (Average = 50 %): 89 %
- Recoil effect (Restricted arc if above 1.00): 0,81
Seaboat quality (Average = 1.00): 1,78
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,545
Length to Beam Ratio: 6,13 : 1
'Natural speed' for length: 20,27 kts
Power going to wave formation at top speed: 43 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): -24,00 degrees
Stern overhang: 0,00 ft / 0,00 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 20,44 ft / 6,23 m
- Forecastle (20%): 19,46 ft / 5,93 m
- Mid (67%): 19,46 ft / 5,93 m (11,48 ft / 3,50 m aft of break)
- Quarterdeck (13%): 11,48 ft / 3,50 m
- Stern: 11,48 ft / 3,50 m
- Average freeboard: 16,90 ft / 5,15 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 94,2%
- Above water (accommodation/working, high = better): 111,6%
Waterplane Area: 19 126 Square feet or 1 777 Square metres
Displacement factor (Displacement / loading): 91%
Structure weight / hull surface area: 154 lbs/sq ft or 754 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 1,07
- Longitudinal: 3,14
- Overall: 1,19
Hull space for machinery, storage, compartmentation is adequate
Room for accommodation and workspaces is adequate
Ship has slow, easy roll, a good, steady gun platform
Excellent seaboat, comfortable, can fire her guns in the heaviest weather
