Dziś włoska mini-Dunkerque :) Czyli okręt w ogólnym zarysie i kształcie zainspirowany tym francuskim pancernikiem, ale w mniejszej skali. Okręt jest uzbrojony w działa 10-calowe nowego typu, wywodzące się z dział model 1908 w jakie wyposażano włoskie krążowniki pancerne (Pisa, San Giorgio). Z typowej artylerii średniej kalibru rzędu 6 cali zrezygnowano, na rzecz baterii dział kal. 100 mm, które od biedy mogą służyć do zwalczania celów latających jak i niedużych pływających (przeciw tym większym konieczne będzie użycie artylerii głównej). Okręt jest przyzwoicie opancerzony (pb 180, pag 180, pp75), i osiąga zadowalające 33 węzły. Można go więc uznać za rodzaj niszczyciela krążowników waszyngtońskich, od większości których wprawdzie nie jest nominalnie szybszy, ale jako jednostka większa, powinien być szybszy realnie (nie powinien tracić z prędkości tyle co one przy gorszych warunkach). Pomysłodawcą okrętu jest kol. ŁK, któremu mam nadzieję taka realizacja się spodoba :)
Ottaviano Augusto, italian large cruiser laid down 1935 (Engine 1937)
Displacement:
16 897 t light; 17 667 t standard; 19 110 t normal; 20 265 t full load
Dimensions: Length overall / water x beam x draught
686,47 ft / 678,12 ft x 76,18 ft x 24,80 ft (normal load)
209,23 m / 206,69 m x 23,22 m x 7,56 m
Armament:
8 - 10,00" / 254 mm guns (2x4 guns), 500,00lbs / 226,80kg shells, 1934 Model
Breech loading guns in turrets (on barbettes)
on centreline, all forward, 1 raised mount - superfiring
12 - 3,94" / 100 mm guns (6x2 guns), 30,51lbs / 13,84kg shells, 1928 Model
Dual purpose guns in deck mounts
on side, all amidships
4 - 3,94" / 100 mm guns (2x2 guns), 30,51lbs / 13,84kg shells, 1928 Model
Dual purpose guns in deck mounts
on side, evenly spread, all raised mounts
16 - 1,46" / 37,0 mm guns (8x2 guns), 1,55lbs / 0,70kg shells, 1932 Model
Anti-aircraft guns in deck mounts
on side ends, evenly spread, 2 raised mounts - superfiring
6 - 0,79" / 20,0 mm guns (3x2 guns), 0,24lbs / 0,11kg shells, 1935 Model
Anti-aircraft guns in deck mounts
on centreline, all amidships, all raised mounts - superfiring
Weight of broadside 4 514 lbs / 2 048 kg
Shells per gun, main battery: 150
Armour:
- Belts: Width (max) Length (avg) Height (avg)
Main: 7,09" / 180 mm 299,77 ft / 91,37 m 6,99 ft / 2,13 m
Ends: 3,94" / 100 mm 131,73 ft / 40,15 m 6,99 ft / 2,13 m
246,62 ft / 75,17 m Unarmoured ends
Upper: 5,91" / 150 mm 299,77 ft / 91,37 m 7,97 ft / 2,43 m
Main Belt covers 68% of normal length
Main belt does not fully cover magazines and engineering spaces
- Torpedo Bulkhead:
1,57" / 40 mm 431,50 ft / 131,52 m 23,79 ft / 7,25 m
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 7,09" / 180 mm 4,72" / 120 mm 7,09" / 180 mm
2nd: 1,57" / 40 mm 0,79" / 20 mm -
3rd: 1,57" / 40 mm 0,79" / 20 mm -
- Armour deck: 2,95" / 75 mm, Conning tower: 7,09" / 180 mm
Machinery:
Oil fired boilers, steam turbines,
Geared drive, 4 shafts, 138 541 shp / 103 352 Kw = 33,00 kts
Range 6 000nm at 17,00 kts
Bunker at max displacement = 2 598 tons
Complement:
812 - 1 056
Cost:
£8,161 million / $32,642 million
Distribution of weights at normal displacement:
Armament: 564 tons, 3,0%
Armour: 4 902 tons, 25,7%
- Belts: 1 446 tons, 7,6%
- Torpedo bulkhead: 598 tons, 3,1%
- Armament: 830 tons, 4,3%
- Armour Deck: 1 919 tons, 10,0%
- Conning Tower: 109 tons, 0,6%
Machinery: 3 840 tons, 20,1%
Hull, fittings & equipment: 7 516 tons, 39,3%
Fuel, ammunition & stores: 2 214 tons, 11,6%
Miscellaneous weights: 75 tons, 0,4%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
24 354 lbs / 11 047 Kg = 48,7 x 10,0 " / 254 mm shells or 3,4 torpedoes
Stability (Unstable if below 1.00): 1,17
Metacentric height 4,5 ft / 1,4 m
Roll period: 15,2 seconds
Steadiness - As gun platform (Average = 50 %): 50 %
- Recoil effect (Restricted arc if above 1.00): 0,48
Seaboat quality (Average = 1.00): 1,01
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,522
Length to Beam Ratio: 8,90 : 1
'Natural speed' for length: 26,04 kts
Power going to wave formation at top speed: 57 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): 8,00 degrees
Stern overhang: 4,49 ft / 1,37 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 27,43 ft / 8,36 m
- Forecastle (23%): 26,44 ft / 8,06 m
- Mid (47%): 25,43 ft / 7,75 m (17,45 ft / 5,32 m aft of break)
- Quarterdeck (17%): 17,95 ft / 5,47 m
- Stern: 18,44 ft / 5,62 m
- Average freeboard: 21,87 ft / 6,67 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 120,6%
- Above water (accommodation/working, high = better): 173,1%
Waterplane Area: 35 123 Square feet or 3 263 Square metres
Displacement factor (Displacement / loading): 111%
Structure weight / hull surface area: 140 lbs/sq ft or 683 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,96
- Longitudinal: 1,35
- Overall: 1,00
Hull space for machinery, storage, compartmentation is cramped
Room for accommodation and workspaces is excellent
1 catapult, 2 seaplanes
Ottaviano Augusto (1937)
Claudio Tiberio (1938)
Ulpio Traiano (1939)
