Dzisiejszy okręt to wczesne wcielenie idei Johna Fishera – coś co można by z przymrużeniem oka nazwać „wielkim lekkim krążownikiem epoki predrednotów”. Generalnie chodzi o okręt z pancernikowym kalibrem artylerii, ale od pancerników istotnie szybszy. Konstrukcyjnie jest to krążownik pancernopokładowy, któremu główną ochronę zapewniają skosy pokładu pancernego wsparte zasobniami węglowymi. Zastosowaniem takiej jednostki może być rozpoznanie na rzecz floty liniowej lub tworzenie jej szybkiego skrzydła, ewentualnie dobijanie uszkodzonych wrogich pancerników.
Marlborough, british large protected cruiser laid down 1896 (Engine 1898)
Displacement:
10 388 t light; 10 792 t standard; 11 593 t normal; 12 234 t full load
Dimensions: Length overall / water x beam x draught
469,29 ft / 466,80 ft x 67,49 ft x 23,85 ft (normal load)
143,04 m / 142,28 m x 20,57 m x 7,27 m
Armament:
2 - 12,01" / 305 mm guns in single mounts, 865,70lbs / 392,67kg shells, 1890 Model
Breech loading guns in turrets (on barbettes)
on centreline ends, evenly spread
16 - 5,98" / 152 mm guns in single mounts, 103,94lbs / 47,15kg shells, 1888 Model
Quick firing guns in casemate mounts
on side, all amidships
12 guns in hull casemates - Limited use in heavy seas
10 - 2,99" / 76,0 mm guns in single mounts, 13,39lbs / 6,07kg shells, 1893 Model
Quick firing guns in casemate mounts
on side, all amidships
4 - 1,85" / 47,0 mm guns in single mounts, 2,93lbs / 1,33kg shells, 1885 Model
Quick firing guns in deck mounts
on centreline ends, evenly spread, all raised mounts - superfiring
Weight of broadside 3 540 lbs / 1 606 kg
Shells per gun, main battery: 80
4 - 18,0" / 457 mm submerged torpedo tubes
Armour:
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 9,21" / 234 mm 7,01" / 178 mm 9,21" / 234 mm
2nd: 2,99" / 76 mm - -
3rd: 2,99" / 76 mm - -
- Armour deck: 2,72" / 69 mm (deck 1,46" / 37 mm, slopes 4,61" / 117 mm), Conning tower: 10,00" / 254 mm
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 24 223 ihp / 18 071 Kw = 22,00 kts
Range 5 000nm at 10,00 kts
Bunker at max displacement = 1 441 tons (100% coal)
Complement:
558 - 726
Cost:
£1,282 million / $5,129 million
Distribution of weights at normal displacement:
Armament: 443 tons, 3,8%
Armour: 1 890 tons, 16,3%
- Belts: 0 tons, 0,0%
- Torpedo bulkhead: 0 tons, 0,0%
- Armament: 685 tons, 5,9%
- Armour Deck: 1 095 tons, 9,4%
- Conning Tower: 110 tons, 1,0%
Machinery: 3 907 tons, 33,7%
Hull, fittings & equipment: 4 148 tons, 35,8%
Fuel, ammunition & stores: 1 205 tons, 10,4%
Miscellaneous weights: 0 tons, 0,0%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
6 936 lbs / 3 146 Kg = 8,0 x 12,0 " / 305 mm shells or 1,0 torpedoes
Stability (Unstable if below 1.00): 1,28
Metacentric height 4,3 ft / 1,3 m
Roll period: 13,6 seconds
Steadiness - As gun platform (Average = 50 %): 100 %
- Recoil effect (Restricted arc if above 1.00): 0,64
Seaboat quality (Average = 1.00): 2,00
Hull form characteristics:
Hull has a flush deck
Block coefficient: 0,540
Length to Beam Ratio: 6,92 : 1
'Natural speed' for length: 21,61 kts
Power going to wave formation at top speed: 49 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): -21,00 degrees
Stern overhang: 2,49 ft / 0,76 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 26,94 ft / 8,21 m
- Forecastle (21%): 22,93 ft / 6,99 m
- Mid (50%): 21,95 ft / 6,69 m
- Quarterdeck (21%): 21,95 ft / 6,69 m
- Stern: 22,44 ft / 6,84 m
- Average freeboard: 22,68 ft / 6,91 m
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 143,8%
- Above water (accommodation/working, high = better): 165,0%
Waterplane Area: 21 781 Square feet or 2 023 Square metres
Displacement factor (Displacement / loading): 88%
Structure weight / hull surface area: 118 lbs/sq ft or 574 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,90
- Longitudinal: 2,54
- Overall: 1,00
Hull space for machinery, storage, compartmentation is cramped
Room for accommodation and workspaces is excellent
Ship has slow, easy roll, a good, steady gun platform
Excellent seaboat, comfortable, can fire her guns in the heaviest weather
Marlborough(1898)
Rupert (1898)
Sandwich (1899)
