Niestety, muszę zapowiedzieć małą przerwę w działalności bloga. Spowodowane jest to remontem jaki sobie zafundowałem i związanym z tym ostrym deficytem wolnego czasu, jak i mocno ograniczonym dostępem do sieci. Myślę, że ta przerwa może potrwać nawet do końca czerwca. Jest możliwe, że coś w tym czasie opublikuję, ale raczej nie będzie tego dużo (zwłaszcza na rysowanie okrętów czasu brakuje, a tymczasem głowę mam pełną pomysłów..). Dlatego zalecam uzbrojenie się w cierpliwość, i jednocześnie obiecuję, że blog powróci, a temat polskiej floty w XIX w. będzie na 100% kontynuowany.
sobota, 24 maja 2014
poniedziałek, 19 maja 2014
Niszczyciel z dwoma działami 75 mm
A oto eksperymentalna wersja niszczyciela z dwoma działami 75 mm. Wagowo faktycznie się
to zgodziło z poprzednią wersją, nawet jest ciut lżejsze, więc wpakowałem
trochę więcej paliwa..
Piorun, polish torpedo boat destroyer laid down 1896
Displacement:
283 t light; 292 t standard; 323 t normal; 347 t full load
Dimensions: Length overall / water x beam x draught
195,32 ft / 193,86 ft x 19,55 ft x 7,25 ft (normal load)
59,53 m / 59,09 m x 5,96 m x 2,21 m
Armament:
2 - 2,95" / 75,0 mm guns in single mounts, 12,87lbs / 5,84kg shells, 1891 Model
Quick firing guns in deck mounts
on centreline ends, evenly spread, 1 raised mount
Weight of broadside 26 lbs / 12 kg
Shells per gun, main battery: 180
3 - 18,0" / 457 mm above water torpedoes
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 8 097 ihp / 6 041 Kw = 27,00 kts
Range 1 590nm at 10,00 kts
Bunker at max displacement = 55 tons (100% coal)
Caution: Delicate, lightweight machinery
Complement:
37 - 49
Cost:
£0,041 million / $0,166 million
Distribution of weights at normal displacement:
Armament: 3 tons, 1,0%
Machinery: 206 tons, 63,9%
Hull, fittings & equipment: 70 tons, 21,8%
Fuel, ammunition & stores: 40 tons, 12,3%
Miscellaneous weights: 3 tons, 0,9%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
52 lbs / 24 Kg = 4,0 x 3,0 " / 75 mm shells or 0,1 torpedoes
Stability (Unstable if below 1.00): 1,59
Metacentric height 0,9 ft / 0,3 m
Roll period: 8,5 seconds
Steadiness - As gun platform (Average = 50 %): 28 %
- Recoil effect (Restricted arc if above 1.00): 0,06
Seaboat quality (Average = 1.00): 0,32
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,411
Length to Beam Ratio: 9,91 : 1
'Natural speed' for length: 13,92 kts
Power going to wave formation at top speed: 70 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): 3,00 degrees
Stern overhang: 0,98 ft / 0,30 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 8,92 ft / 2,72 m
- Forecastle (19%): 10,40 ft / 3,17 m
- Mid (24%): 10,40 ft / 3,17 m (6,43 ft / 1,96 m aft of break)
- Quarterdeck (15%): 5,91 ft / 1,80 m
- Stern: 6,43 ft / 1,96 m
- Average freeboard: 7,07 ft / 2,16 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 214,7%
- Above water (accommodation/working, high = better): 47,1%
Waterplane Area: 2 349 Square feet or 218 Square metres
Displacement factor (Displacement / loading): 12%
Structure weight / hull surface area: 17 lbs/sq ft or 83 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,46
- Longitudinal: 1,05
- Overall: 0,50
Hull space for machinery, storage, compartmentation is extremely poor
Room for accommodation and workspaces is extremely poor
Ship has quick, lively roll, not a steady gun platform
Caution: Lacks seaworthiness - very limited seakeeping ability
sobota, 17 maja 2014
Zmodyfikowany niszczyciel
Dziś prezentuję poprawioną wersję niszczyciela. Okręt jest
identycznie uzbrojony, ale ciut większy, przez co udało się uzyskać nieco
większą prędkość. Co do położenia działa 75 mm – próbowałem je obniżyć, ale niewiele z
tego wyszło – kadłub jest ciut wyższy, nadbudówka niższa, więc w sumie działo
pozostało z grubsza na tym samym poziomie. Natomiast w następnej wersji
niszczyciela postaram się zmodyfikować uzbrojenie, zgodnie z sugestią
ujednolicenia uzbrojenia do 2 dział 75 mm. Zobaczymy co z tego wyjdzie:)
ps. nazwy nowych niszczycieli są jakby znajome:)
Grom, polish torpedo boat destroyer laid down 1896
Displacement:
283 t light; 293 t standard; 322 t normal; 345 t full load
Dimensions: Length overall / water x beam x draught
195,32 ft / 193,86 ft x 19,55 ft x 7,25 ft (normal load)
59,53 m / 59,09 m x 5,96 m x 2,21 m
Armament:
1 - 2,95" / 75,0 mm guns in single mounts, 12,87lbs / 5,84kg shells, 1891 Model
Quick firing gun in deck mount
on centreline forward, 1 raised gun
2 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in deck mounts
on side, all forward
1 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing gun in deck mount
on centreline aft
Weight of broadside 29 lbs / 13 kg
Shells per gun, main battery: 180
3 - 18,0" / 457 mm above water torpedoes
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 8 079 ihp / 6 027 Kw = 27,00 kts
Range 1 500nm at 10,00 kts
Bunker at max displacement = 52 tons (100% coal)
Caution: Delicate, lightweight machinery
Complement:
37 - 49
Cost:
£0,042 million / $0,167 million
Distribution of weights at normal displacement:
Armament: 4 tons, 1,1%
Machinery: 206 tons, 63,9%
Hull, fittings & equipment: 71 tons, 22,0%
Fuel, ammunition & stores: 39 tons, 12,1%
Miscellaneous weights: 3 tons, 0,9%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
51 lbs / 23 Kg = 4,0 x 3,0 " / 75 mm shells or 0,1 torpedoes
Stability (Unstable if below 1.00): 1,59
Metacentric height 0,9 ft / 0,3 m
Roll period: 8,5 seconds
Steadiness - As gun platform (Average = 50 %): 28 %
- Recoil effect (Restricted arc if above 1.00): 0,07
Seaboat quality (Average = 1.00): 0,31
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,410
Length to Beam Ratio: 9,91 : 1
'Natural speed' for length: 13,92 kts
Power going to wave formation at top speed: 70 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): 3,00 degrees
Stern overhang: 0,98 ft / 0,30 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 8,92 ft / 2,72 m
- Forecastle (19%): 10,40 ft / 3,17 m
- Mid (24%): 10,40 ft / 3,17 m (6,43 ft / 1,96 m aft of break)
- Quarterdeck (15%): 5,91 ft / 1,80 m
- Stern: 6,43 ft / 1,96 m
- Average freeboard: 7,07 ft / 2,16 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 215,6%
- Above water (accommodation/working, high = better): 47,1%
Waterplane Area: 2 348 Square feet or 218 Square metres
Displacement factor (Displacement / loading): 12%
Structure weight / hull surface area: 17 lbs/sq ft or 84 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,46
- Longitudinal: 1,04
- Overall: 0,50
Hull space for machinery, storage, compartmentation is extremely poor
Room for accommodation and workspaces is extremely poor
Ship has quick, lively roll, not a steady gun platform
Caution: Lacks seaworthiness - very limited seakeeping ability
Grom (1896)
Błyskawica (1896)
Wicher (1896)
Burza (1896)
Displacement:
283 t light; 293 t standard; 322 t normal; 345 t full load
Dimensions: Length overall / water x beam x draught
195,32 ft / 193,86 ft x 19,55 ft x 7,25 ft (normal load)
59,53 m / 59,09 m x 5,96 m x 2,21 m
Armament:
1 - 2,95" / 75,0 mm guns in single mounts, 12,87lbs / 5,84kg shells, 1891 Model
Quick firing gun in deck mount
on centreline forward, 1 raised gun
2 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in deck mounts
on side, all forward
1 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing gun in deck mount
on centreline aft
Weight of broadside 29 lbs / 13 kg
Shells per gun, main battery: 180
3 - 18,0" / 457 mm above water torpedoes
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 8 079 ihp / 6 027 Kw = 27,00 kts
Range 1 500nm at 10,00 kts
Bunker at max displacement = 52 tons (100% coal)
Caution: Delicate, lightweight machinery
Complement:
37 - 49
Cost:
£0,042 million / $0,167 million
Distribution of weights at normal displacement:
Armament: 4 tons, 1,1%
Machinery: 206 tons, 63,9%
Hull, fittings & equipment: 71 tons, 22,0%
Fuel, ammunition & stores: 39 tons, 12,1%
Miscellaneous weights: 3 tons, 0,9%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
51 lbs / 23 Kg = 4,0 x 3,0 " / 75 mm shells or 0,1 torpedoes
Stability (Unstable if below 1.00): 1,59
Metacentric height 0,9 ft / 0,3 m
Roll period: 8,5 seconds
Steadiness - As gun platform (Average = 50 %): 28 %
- Recoil effect (Restricted arc if above 1.00): 0,07
Seaboat quality (Average = 1.00): 0,31
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,410
Length to Beam Ratio: 9,91 : 1
'Natural speed' for length: 13,92 kts
Power going to wave formation at top speed: 70 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): 3,00 degrees
Stern overhang: 0,98 ft / 0,30 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 8,92 ft / 2,72 m
- Forecastle (19%): 10,40 ft / 3,17 m
- Mid (24%): 10,40 ft / 3,17 m (6,43 ft / 1,96 m aft of break)
- Quarterdeck (15%): 5,91 ft / 1,80 m
- Stern: 6,43 ft / 1,96 m
- Average freeboard: 7,07 ft / 2,16 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 215,6%
- Above water (accommodation/working, high = better): 47,1%
Waterplane Area: 2 348 Square feet or 218 Square metres
Displacement factor (Displacement / loading): 12%
Structure weight / hull surface area: 17 lbs/sq ft or 84 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,46
- Longitudinal: 1,04
- Overall: 0,50
Hull space for machinery, storage, compartmentation is extremely poor
Room for accommodation and workspaces is extremely poor
Ship has quick, lively roll, not a steady gun platform
Caution: Lacks seaworthiness - very limited seakeeping ability
Grom (1896)
Błyskawica (1896)
Wicher (1896)
Burza (1896)
czwartek, 15 maja 2014
Pierwszy niszczyciel
Dziwne że się jeszcze nikt nie dopomina niszczycieli;)
Postanowiłem naprawić ten mankament naszej floty, i oto jest – nasz pierwszy
niszczyciel! Po sylwetce dość łatwo można się domyślić jego brytyjskiej
proweniencji, i nie ma w tym nic dziwnego, bowiem to właśnie Brytyjczycy wiedli
w latach 90-tych XIX w. prym w budowie okrętów tej klasy (pierwszy okręt
powszechnie uważany za niszczyciel – Havoc, to ich dzieło), i sporo ich
zbudowali dla różnych flot. Oczywiście, pamiętam cały czas że układ
geopolityczny jest taki, że Anglia jest nam raczej nieprzychylna a nasza flota
potencjalnie może być dla Royal Navy przeciwnikiem, ale business is business –
i skoro mogli budować okręty dla Rosji (np. pierwszy rosyjski niszczyciel Sokoł,
późniejszy Prytkij został zbudowany przez stocznię Yarrow), to mogą i dla nas.
Okazuje się, że prywatnej stoczni rząd nie bardzo mógł (albo chciał..) zakazać
budowy okrętów dla floty państwa będącego potencjalnym przeciwnikiem –
przynajmniej jeśli chodzi o takie „drobnoustroje”..
Zakładam, że pierwszy niszczyciel powstanie w Wielkiej
Brytanii, a kolejne, stanowiące jego rozwinięcie, już w rodzimych stoczniach
(bo po tylu latach rozwoju floty to jakiegoś rodzimego przemysłu stoczniowego
już się raczej dorobiliśmy;))
Szkwał, polish torpedo boat destroyer laid down 1895
Displacement:
253 t light; 263 t standard; 290 t normal; 312 t full load
Dimensions: Length overall / water x beam x draught
188,83 ft / 186,38 ft x 18,90 ft x 7,09 ft (normal load)
57,55 m / 56,81 m x 5,76 m x 2,16 m
Armament:
1 - 2,95" / 75,0 mm guns in single mounts, 12,87lbs / 5,84kg shells, 1891 Model
Quick firing gun in deck mount
on centreline forward, 1 raised gun
2 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in deck mounts
on side, all forward
1 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing gun in deck mount
on centreline aft
Weight of broadside 29 lbs / 13 kg
Shells per gun, main battery: 180
3 - 18,0" / 457 mm above water torpedoes
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 6 790 ihp / 5 065 Kw = 26,20 kts
Range 1 500nm at 10,00 kts
Bunker at max displacement = 50 tons (100% coal)
Caution: Delicate, lightweight machinery
Complement:
34 - 45
Cost:
£0,038 million / $0,150 million
Distribution of weights at normal displacement:
Armament: 4 tons, 1,2%
Machinery: 184 tons, 63,3%
Hull, fittings & equipment: 63 tons, 21,6%
Fuel, ammunition & stores: 37 tons, 12,8%
Miscellaneous weights: 3 tons, 1,0%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
45 lbs / 21 Kg = 3,5 x 3,0 " / 75 mm shells or 0,1 torpedoes
Stability (Unstable if below 1.00): 1,56
Metacentric height 0,9 ft / 0,3 m
Roll period: 8,5 seconds
Steadiness - As gun platform (Average = 50 %): 27 %
- Recoil effect (Restricted arc if above 1.00): 0,08
Seaboat quality (Average = 1.00): 0,29
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,407
Length to Beam Ratio: 9,86 : 1
'Natural speed' for length: 13,65 kts
Power going to wave formation at top speed: 70 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): 3,00 degrees
Stern overhang: 2,00 ft / 0,61 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 8,40 ft / 2,56 m
- Forecastle (16%): 10,01 ft / 3,05 m
- Mid (22%): 10,01 ft / 3,05 m (6,00 ft / 1,83 m aft of break)
- Quarterdeck (13%): 5,51 ft / 1,68 m
- Stern: 6,00 ft / 1,83 m
- Average freeboard: 6,58 ft / 2,01 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 215,1%
- Above water (accommodation/working, high = better): 42,5%
Waterplane Area: 2 177 Square feet or 202 Square metres
Displacement factor (Displacement / loading): 12%
Structure weight / hull surface area: 17 lbs/sq ft or 82 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,47
- Longitudinal: 0,96
- Overall: 0,50
Hull space for machinery, storage, compartmentation is extremely poor
Room for accommodation and workspaces is extremely poor
Ship has quick, lively roll, not a steady gun platform
Caution: Lacks seaworthiness - very limited seakeeping ability
Displacement:
253 t light; 263 t standard; 290 t normal; 312 t full load
Dimensions: Length overall / water x beam x draught
188,83 ft / 186,38 ft x 18,90 ft x 7,09 ft (normal load)
57,55 m / 56,81 m x 5,76 m x 2,16 m
Armament:
1 - 2,95" / 75,0 mm guns in single mounts, 12,87lbs / 5,84kg shells, 1891 Model
Quick firing gun in deck mount
on centreline forward, 1 raised gun
2 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in deck mounts
on side, all forward
1 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing gun in deck mount
on centreline aft
Weight of broadside 29 lbs / 13 kg
Shells per gun, main battery: 180
3 - 18,0" / 457 mm above water torpedoes
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 6 790 ihp / 5 065 Kw = 26,20 kts
Range 1 500nm at 10,00 kts
Bunker at max displacement = 50 tons (100% coal)
Caution: Delicate, lightweight machinery
Complement:
34 - 45
Cost:
£0,038 million / $0,150 million
Distribution of weights at normal displacement:
Armament: 4 tons, 1,2%
Machinery: 184 tons, 63,3%
Hull, fittings & equipment: 63 tons, 21,6%
Fuel, ammunition & stores: 37 tons, 12,8%
Miscellaneous weights: 3 tons, 1,0%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
45 lbs / 21 Kg = 3,5 x 3,0 " / 75 mm shells or 0,1 torpedoes
Stability (Unstable if below 1.00): 1,56
Metacentric height 0,9 ft / 0,3 m
Roll period: 8,5 seconds
Steadiness - As gun platform (Average = 50 %): 27 %
- Recoil effect (Restricted arc if above 1.00): 0,08
Seaboat quality (Average = 1.00): 0,29
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,407
Length to Beam Ratio: 9,86 : 1
'Natural speed' for length: 13,65 kts
Power going to wave formation at top speed: 70 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): 3,00 degrees
Stern overhang: 2,00 ft / 0,61 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 8,40 ft / 2,56 m
- Forecastle (16%): 10,01 ft / 3,05 m
- Mid (22%): 10,01 ft / 3,05 m (6,00 ft / 1,83 m aft of break)
- Quarterdeck (13%): 5,51 ft / 1,68 m
- Stern: 6,00 ft / 1,83 m
- Average freeboard: 6,58 ft / 2,01 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 215,1%
- Above water (accommodation/working, high = better): 42,5%
Waterplane Area: 2 177 Square feet or 202 Square metres
Displacement factor (Displacement / loading): 12%
Structure weight / hull surface area: 17 lbs/sq ft or 82 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,47
- Longitudinal: 0,96
- Overall: 0,50
Hull space for machinery, storage, compartmentation is extremely poor
Room for accommodation and workspaces is extremely poor
Ship has quick, lively roll, not a steady gun platform
Caution: Lacks seaworthiness - very limited seakeeping ability
sobota, 10 maja 2014
Krążownik pancerny
Długo zapowiadałem krążownik pancerny z prawdziwego
zdarzenia i oto jest! W stosunku do poprzedników, będących przebudowanymi
starymi pancernikami jest to istotny postęp, i to w zasadzie pod każdym
względem. 2 działa kal. 254
mm i 10 szybkostrzelnych kal. 152 mm to siła ognia nieporównywalnie
większa niż 10 dział 203 mm
w kazamatach na poprzednim typie, w dodatku nowocześniej ustawiona, bowiem
działa artylerii głównej znajdują się w wieżach działowych mogących prowadzić
ogień na obydwie burty. Na pierwszy rzut oka tego może nie widać, ale jeśli
uwzględnić szybkostrzelność nowoczesnych dział 152 mm, to okazuje się, że
nowy krążownik może w ciągu 10 minut wysłać w kierunku wroga ponad 17 ton
pocisków, podczas gdy poprzednik z 5 dział znajdujących się na jednej burcie –
ledwo 5 ton! Również opancerzenie jest
krokiem do przodu. 200 mm
zastosowanej tu stali utwardzanej metodą Harveya na burcie to ekwiwalent 320 mm „zwykłego” pancerza
stalowego, a przypomnę, że poprzednie typy miały 250 mm i 213 mm (stali
nieutwardzonej). Zatem wytrzymałość pancerza, mimo mniejszej grubości, jest
wyższa niż na starszych typach. Na koniec dodam, że osiągając 19,4 w., nasz
nowy okręt zostawia w tyle swoich poprzedników, i nie odstaje w tym względzie
od ówczesnego standardu dla tej klasy okrętów.
Piast, polish armoured cruiser laid down 1893 (Engine 1894)
Displacement:
6 979 t light; 7 257 t standard; 8 054 t normal; 8 691 t full load
Dimensions: Length overall / water x beam x draught
381,23 ft / 380,25 ft x 58,46 ft x 23,52 ft (normal load)
116,20 m / 115,90 m x 17,82 m x 7,17 m
Armament:
2 - 10,00" / 254 mm guns in single mounts, 500,00lbs / 226,80kg shells, 1891 Model
Breech loading guns in turrets (on barbettes)
on centreline ends, evenly spread
10 - 5,98" / 152 mm guns in single mounts, 107,15lbs / 48,60kg shells, 1891 Model
Quick firing guns in casemate mounts
on side, all amidships
4 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in casemate mounts
on side ends, evenly spread
4 guns in hull casemates - Limited use in all but light seas
8 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in deck mounts
on side ends, evenly spread, 4 raised mounts - superfiring
Weight of broadside 2 134 lbs / 968 kg
Shells per gun, main battery: 90
4 - 18,0" / 457 mm submerged torpedo tubes
Armour:
- Belts: Width (max) Length (avg) Height (avg)
Main: 7,87" / 200 mm 201,35 ft / 61,37 m 9,28 ft / 2,83 m
Ends: 5,79" / 147 mm 93,54 ft / 28,51 m 9,28 ft / 2,83 m
85,37 ft / 26,02 m Unarmoured ends
Main Belt covers 81% of normal length
Main belt does not fully cover magazines and engineering spaces
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 8,86" / 225 mm 5,51" / 140 mm 7,52" / 191 mm
2nd: 7,09" / 180 mm - -
3rd: 3,94" / 100 mm - -
- Armour deck: 2,01" / 51 mm, Conning tower: 10,51" / 267 mm
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 12 761 ihp / 9 520 Kw = 19,40 kts
Range 6 000nm at 10,00 kts
Bunker at max displacement = 1 434 tons (100% coal)
Complement:
424 - 552
Cost:
£0,776 million / $3,106 million
Distribution of weights at normal displacement:
Armament: 267 tons, 3,3%
Armour: 2 037 tons, 25,3%
- Belts: 858 tons, 10,7%
- Torpedo bulkhead: 0 tons, 0,0%
- Armament: 518 tons, 6,4%
- Armour Deck: 570 tons, 7,1%
- Conning Tower: 91 tons, 1,1%
Machinery: 2 200 tons, 27,3%
Hull, fittings & equipment: 2 470 tons, 30,7%
Fuel, ammunition & stores: 1 075 tons, 13,3%
Miscellaneous weights: 4 tons, 0,0%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
5 702 lbs / 2 586 Kg = 11,4 x 10,0 " / 254 mm shells or 1,0 torpedoes
Stability (Unstable if below 1.00): 1,31
Metacentric height 3,6 ft / 1,1 m
Roll period: 12,9 seconds
Steadiness - As gun platform (Average = 50 %): 79 %
- Recoil effect (Restricted arc if above 1.00): 0,35
Seaboat quality (Average = 1.00): 1,58
Hull form characteristics:
Hull has a flush deck
Block coefficient: 0,539
Length to Beam Ratio: 6,50 : 1
'Natural speed' for length: 19,50 kts
Power going to wave formation at top speed: 49 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): -22,00 degrees
Stern overhang: 0,98 ft / 0,30 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 17,09 ft / 5,21 m
- Forecastle (16%): 15,52 ft / 4,73 m
- Mid (50%): 14,63 ft / 4,46 m
- Quarterdeck (19%): 15,45 ft / 4,71 m
- Stern: 16,90 ft / 5,15 m
- Average freeboard: 15,45 ft / 4,71 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 121,3%
- Above water (accommodation/working, high = better): 103,9%
Waterplane Area: 15 356 Square feet or 1 427 Square metres
Displacement factor (Displacement / loading): 94%
Structure weight / hull surface area: 102 lbs/sq ft or 498 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,92
- Longitudinal: 2,16
- Overall: 1,00
Hull space for machinery, storage, compartmentation is cramped
Room for accommodation and workspaces is adequate
Ship has slow, easy roll, a good, steady gun platform
Excellent seaboat, comfortable, can fire her guns in the heaviest weather
Piast (1894)
Siemowit (1895)
środa, 7 maja 2014
"Ciężki" krążownik kolonialny
Oto zapowiadany krążownik, który ma być swego rodzaju
ersatzem pancernika w posiadłościach zamorskich. Jakichś poważniejszych walk z większymi siłami wroga nie przewiduję, więc ani prędkośc ani opancerzenie nie są imponujące. Za to duże działa (czy może raczej działo) to wymowny i widoczny na pierwszy rzut oka argument. Do "prezentowania bandery" na odległych akwenach powinien się przydać. W związku z wejściem posiadanie
kolonii w Chinach, okręt może być np. trzonem nowej eskadry dalekowschodniej. Ciekawe jak się spodoba, bo chyba jest dość niekonwencjonalny (choć jak najbardziej w duchu XIX w., kiedy powstało trochę tego rodzaju jednostek).
Stefan Czarniecki, polish protected cruiser laid down 1892 (Engine 1894)
Displacement:
3 948 t light; 4 107 t standard; 4 438 t normal; 4 703 t full load
Dimensions: Length overall / water x beam x draught
315,12 ft / 313,62 ft x 50,33 ft x 18,96 ft (normal load)
96,05 m / 95,59 m x 15,34 m x 5,78 m
Armament:
1 - 12,01" / 305 mm guns in single mounts, 813,76lbs / 369,12kg shells, 1886 Model
Breech loading gun in a turret (on a barbette)
on centreline forward
Main guns limited to end-on fire
1 - 9,02" / 229 mm guns in single mounts, 366,42lbs / 166,21kg shells, 1892 Model
Breech loading gun in a deck mount with hoist
on centreline aft
8 - 4,72" / 120 mm guns in single mounts, 52,72lbs / 23,91kg shells, 1891 Model
Quick firing guns in deck mounts with hoists
on side, all amidships
10 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in casemate mounts
on side, evenly spread
10 guns in hull casemates - Limited use in heavy seas
Weight of broadside 1 654 lbs / 750 kg
Shells per gun, main battery: 70
4 - 18,0" / 457 mm above water torpedoes
Armour:
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 6,54" / 166 mm 4,13" / 105 mm 10,0" / 254 mm
2nd: 4,33" / 110 mm 3,27" / 83 mm -
3rd: 2,01" / 51 mm 0,98" / 25 mm -
4th: 1,57" / 40 mm - -
- Armour deck: 2,48" / 63 mm, Conning tower: 10,98" / 279 mm
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 5 636 ihp / 4 204 Kw = 17,00 kts
Range 4 450nm at 9,00 kts
Bunker at max displacement = 596 tons (100% coal)
Complement:
271 - 353
Cost:
£0,448 million / $1,792 million
Distribution of weights at normal displacement:
Armament: 207 tons, 4,7%
Armour: 819 tons, 18,5%
- Belts: 0 tons, 0,0%
- Torpedo bulkhead: 0 tons, 0,0%
- Armament: 264 tons, 6,0%
- Armour Deck: 491 tons, 11,1%
- Conning Tower: 64 tons, 1,4%
Machinery: 972 tons, 21,9%
Hull, fittings & equipment: 1 946 tons, 43,9%
Fuel, ammunition & stores: 490 tons, 11,0%
Miscellaneous weights: 4 tons, 0,1%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
4 504 lbs / 2 043 Kg = 5,2 x 12,0 " / 305 mm shells or 1,0 torpedoes
Stability (Unstable if below 1.00): 1,05
Metacentric height 2,0 ft / 0,6 m
Roll period: 15,1 seconds
Steadiness - As gun platform (Average = 50 %): 100 %
- Recoil effect (Restricted arc if above 1.00): 1,20
Seaboat quality (Average = 1.00): 2,00
Hull form characteristics:
Hull has a flush deck
Block coefficient: 0,519
Length to Beam Ratio: 6,23 : 1
'Natural speed' for length: 17,71 kts
Power going to wave formation at top speed: 46 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): -18,00 degrees
Stern overhang: 1,51 ft / 0,46 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 19,88 ft / 6,06 m
- Forecastle (19%): 18,41 ft / 5,61 m
- Mid (50%): 16,90 ft / 5,15 m
- Quarterdeck (17%): 17,78 ft / 5,42 m
- Stern: 18,80 ft / 5,73 m
- Average freeboard: 17,91 ft / 5,46 m
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 105,5%
- Above water (accommodation/working, high = better): 114,7%
Waterplane Area: 10 701 Square feet or 994 Square metres
Displacement factor (Displacement / loading): 100%
Structure weight / hull surface area: 106 lbs/sq ft or 519 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,85
- Longitudinal: 4,31
- Overall: 1,00
Hull space for machinery, storage, compartmentation is adequate
Room for accommodation and workspaces is adequate
Ship has slow, easy roll, a good, steady gun platform
Excellent seaboat, comfortable, can fire her guns in the heaviest weather
Displacement:
3 948 t light; 4 107 t standard; 4 438 t normal; 4 703 t full load
Dimensions: Length overall / water x beam x draught
315,12 ft / 313,62 ft x 50,33 ft x 18,96 ft (normal load)
96,05 m / 95,59 m x 15,34 m x 5,78 m
Armament:
1 - 12,01" / 305 mm guns in single mounts, 813,76lbs / 369,12kg shells, 1886 Model
Breech loading gun in a turret (on a barbette)
on centreline forward
Main guns limited to end-on fire
1 - 9,02" / 229 mm guns in single mounts, 366,42lbs / 166,21kg shells, 1892 Model
Breech loading gun in a deck mount with hoist
on centreline aft
8 - 4,72" / 120 mm guns in single mounts, 52,72lbs / 23,91kg shells, 1891 Model
Quick firing guns in deck mounts with hoists
on side, all amidships
10 - 2,24" / 57,0 mm guns in single mounts, 5,23lbs / 2,37kg shells, 1885 Model
Quick firing guns in casemate mounts
on side, evenly spread
10 guns in hull casemates - Limited use in heavy seas
Weight of broadside 1 654 lbs / 750 kg
Shells per gun, main battery: 70
4 - 18,0" / 457 mm above water torpedoes
Armour:
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 6,54" / 166 mm 4,13" / 105 mm 10,0" / 254 mm
2nd: 4,33" / 110 mm 3,27" / 83 mm -
3rd: 2,01" / 51 mm 0,98" / 25 mm -
4th: 1,57" / 40 mm - -
- Armour deck: 2,48" / 63 mm, Conning tower: 10,98" / 279 mm
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 5 636 ihp / 4 204 Kw = 17,00 kts
Range 4 450nm at 9,00 kts
Bunker at max displacement = 596 tons (100% coal)
Complement:
271 - 353
Cost:
£0,448 million / $1,792 million
Distribution of weights at normal displacement:
Armament: 207 tons, 4,7%
Armour: 819 tons, 18,5%
- Belts: 0 tons, 0,0%
- Torpedo bulkhead: 0 tons, 0,0%
- Armament: 264 tons, 6,0%
- Armour Deck: 491 tons, 11,1%
- Conning Tower: 64 tons, 1,4%
Machinery: 972 tons, 21,9%
Hull, fittings & equipment: 1 946 tons, 43,9%
Fuel, ammunition & stores: 490 tons, 11,0%
Miscellaneous weights: 4 tons, 0,1%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
4 504 lbs / 2 043 Kg = 5,2 x 12,0 " / 305 mm shells or 1,0 torpedoes
Stability (Unstable if below 1.00): 1,05
Metacentric height 2,0 ft / 0,6 m
Roll period: 15,1 seconds
Steadiness - As gun platform (Average = 50 %): 100 %
- Recoil effect (Restricted arc if above 1.00): 1,20
Seaboat quality (Average = 1.00): 2,00
Hull form characteristics:
Hull has a flush deck
Block coefficient: 0,519
Length to Beam Ratio: 6,23 : 1
'Natural speed' for length: 17,71 kts
Power going to wave formation at top speed: 46 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): -18,00 degrees
Stern overhang: 1,51 ft / 0,46 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 19,88 ft / 6,06 m
- Forecastle (19%): 18,41 ft / 5,61 m
- Mid (50%): 16,90 ft / 5,15 m
- Quarterdeck (17%): 17,78 ft / 5,42 m
- Stern: 18,80 ft / 5,73 m
- Average freeboard: 17,91 ft / 5,46 m
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 105,5%
- Above water (accommodation/working, high = better): 114,7%
Waterplane Area: 10 701 Square feet or 994 Square metres
Displacement factor (Displacement / loading): 100%
Structure weight / hull surface area: 106 lbs/sq ft or 519 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,85
- Longitudinal: 4,31
- Overall: 1,00
Hull space for machinery, storage, compartmentation is adequate
Room for accommodation and workspaces is adequate
Ship has slow, easy roll, a good, steady gun platform
Excellent seaboat, comfortable, can fire her guns in the heaviest weather
czwartek, 1 maja 2014
Transportowce
Dzisiaj prezentuję dwa statki, które zostały przejęte przez
Marynarkę Wojenną od cywilnego armatora w 1890 r., tuż po zwodowaniu, w celu
zapewnienia możliwości transportu własnych oddziałów na Madagaskar. Ponieważ
kwestia transportu własnych oddziałów przy okazji poprzednich działań
(Madagaskar 1883, Hajnan 1884) została przez dowództwo zaniedbana i trzeba było
w tym względzie korzystać z łaski sojusznika (Francja), drugi raz ten sam błąd
nie zostanie popełniony. Zakładam, że z dwóch przejętych jednostek jedna
zostanie przez flotę odkupiona i będzie na stałe pełnić rolę transportowca, zaś
druga po zajęciu wyspy zostanie zwrócona właścicielowi.
Polesie, polish troopship/cargo laid down 1888 (Engine 1890)
Displacement:
5 373 t light; 5 500 t standard; 6 128 t normal; 6 630 t full load
Dimensions: Length overall / water x beam x draught
409,65 ft / 381,73 ft x 47,44 ft x 22,18 ft (normal load)
124,86 m / 116,35 m x 14,46 m x 6,76 m
Armament:
2 - 4,21" / 107 mm guns in single mounts, 24,48lbs / 11,10kg shells, 1867 Model
Breech loading guns in deck mounts
on centreline ends, evenly spread
Weight of broadside 49 lbs / 22 kg
Shells per gun, main battery: 150
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 4 836 ihp / 3 608 Kw = 15,70 kts
Range 8 000nm at 8,00 kts
Bunker at max displacement = 1 131 tons (100% coal)
Complement:
277
Cost:
£0,319 million / $1,274 million
Distribution of weights at normal displacement:
Armament: 6 tons, 0,1%
Machinery: 896 tons, 14,6%
Hull, fittings & equipment: 1 748 tons, 28,5%
Fuel, ammunition & stores: 755 tons, 12,3%
Miscellaneous weights: 2 723 tons, 44,4%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
3 450 lbs / 1 565 Kg = 95,2 x 4,2 " / 107 mm shells or 0,6 torpedoes
Stability (Unstable if below 1.00): 0,88
Metacentric height 1,3 ft / 0,4 m
Roll period: 17,8 seconds
Steadiness - As gun platform (Average = 50 %): 70 %
- Recoil effect (Restricted arc if above 1.00): 0,01
Seaboat quality (Average = 1.00): 2,00
Hull form characteristics:
Hull has raised forecastle, raised quarterdeck
Block coefficient: 0,534
Length to Beam Ratio: 8,05 : 1
'Natural speed' for length: 19,54 kts
Power going to wave formation at top speed: 35 %
Trim (Max stability = 0, Max steadiness = 100): 35
Bow angle (Positive = bow angles forward): 1,00 degrees
Stern overhang: 27,43 ft / 8,36 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 28,41 ft / 8,66 m
- Forecastle (16%): 22,44 ft / 6,84 m (15,45 ft / 4,71 m aft of break)
- Mid (50%): 13,98 ft / 4,26 m
- Quarterdeck (11%): 18,96 ft / 5,78 m (14,47 ft / 4,41 m before break)
- Stern: 20,44 ft / 6,23 m
- Average freeboard: 16,71 ft / 5,09 m
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 96,8%
- Above water (accommodation/working, high = better): 99,0%
Waterplane Area: 12 451 Square feet or 1 157 Square metres
Displacement factor (Displacement / loading): 134%
Structure weight / hull surface area: 78 lbs/sq ft or 383 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,98
- Longitudinal: 2,32
- Overall: 1,07
Hull space for machinery, storage, compartmentation is adequate
Room for accommodation and workspaces is adequate
Ship has slow, easy roll, a good, steady gun platform
Excellent seaboat, comfortable, can fire her guns in the heaviest weather
800 soldiers
Polesie (1890)
Żmudź (1890)
Subskrybuj:
Posty (Atom)
