Pod koniec XIX w., po przegranej wojnie z Japonią, w Chinach pojawiły się plany odbudowy floty wojennej. W 1896 r., francuski projektant Charles Doyere przedstawił rządowi chińskiemu dwa projekty pancerników obrony wybrzeża. Mniejszy przewidywał okręt o wyporności 2900 ton, a większy – 5600 ton. Znane są tylko rzuty boczne tych okrętów oraz jeden artykuł po… chińsku, który mimo użycia translatora wiele szczegółów nie przekazuje. Coś niecoś da się wywnioskować z rysunku. Okręt większy, który wziąłem na warsztat, zdaje się mieć francusko wyglądające kształty kadłuba, nieco podobne do typu Jemmapes i podobne chyba uzbrojenie w długolufowe działa 340 mm (lub 305 mm). Ma też artylerię mniejszego kalibru (164 mm?), również w wieżach. Z przodu okręt posiada maszt bojowy wzorowany na tym z Dupuy de Lome i innych krążowników francuskich, mieszczący najwyraźniej kilka lekkich działek przeciw torpedowcom. Okręt posiada dwa kominy i stosunkowo długie śródokręcie (obszar pomiędzy skrajnymi wieżami) co zdaje się sugerować znaczną moc napędu i prawdopodobnie relatywnie znaczną prędkość. Tyle wywnioskowałem z rysunku, reszta to już moja czysta fantazja, limitowana springsharpem ;)
Oryginalny szkic okrętu wygląda tak: https://mmbiz.qpic.cn/mmbiz_png/hbP5w7mc7lTT2VderjkuQbqAIHYovicEm1kevts95TQTvHkE9EBa5l2vE9KYyPicVRc6r8SDlt4ONaIeaMepeY4Q/640?wx_fmt=png&wxfrom=5&wx_lazy=1&wx_co=1
A tu wspomniany artykuł: https://mp.weixin.qq.com/s/7zzQKo5MQbrYyXrn2TWKvw
Dingyuan, chinese coast defence battleship laid down 1896 (Engine 1897)
Displacement:
5 191 t light; 5 376 t standard; 5 629 t normal; 5 832 t full load
Dimensions: Length overall / water x beam x draught
308,23 ft / 308,23 ft x 54,33 ft x 21,39 ft (normal load)
93,95 m / 93,95 m x 16,56 m x 6,52 m
Armament:
2 - 12,01" / 305 mm guns in single mounts, 826,75lbs / 375,01kg shells, 1887 Model
Breech loading guns in turrets (on barbettes)
on centreline ends, evenly spread
2 - 6,46" / 164 mm guns in single mounts, 134,59lbs / 61,05kg shells, 1891 Model
Quick firing guns in turrets (on barbettes)
on side, all amidships
1 - 6,46" / 164 mm guns in single mounts, 134,59lbs / 61,05kg shells, 1891 Model
Quick firing gun in a turret (on a barbette)
on centreline aft, 1 raised gun
6 - 1,85" / 47,0 mm guns in single mounts, 2,93lbs / 1,33kg shells, 1885 Model
Quick firing guns in deck mounts
on side, all amidships
4 - 1,46" / 37,0 mm guns in single mounts, 1,43lbs / 0,65kg shells, 1885 Model
Quick firing guns in deck mounts
on centreline, all forward, all raised mounts - superfiring
Weight of broadside 2 081 lbs / 944 kg
Shells per gun, main battery: 60
2 - 17,7" / 450 mm submerged torpedo tubes
Armour:
- Belts: Width (max) Length (avg) Height (avg)
Main: 9,84" / 250 mm 213,32 ft / 65,02 m 6,00 ft / 1,83 m
Ends: 5,91" / 150 mm 94,88 ft / 28,92 m 6,00 ft / 1,83 m
Upper: 7,87" / 200 mm 212,30 ft / 64,71 m 5,97 ft / 1,82 m
Main Belt covers 106% of normal length
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 11,0" / 280 mm 5,91" / 150 mm 9,84" / 250 mm
2nd: 3,94" / 100 mm 1,97" / 50 mm 3,15" / 80 mm
3rd: 3,94" / 100 mm 1,97" / 50 mm 3,15" / 80 mm
- Armour deck: 1,97" / 50 mm, Conning tower: 3,94" / 100 mm
Machinery:
Coal fired boilers, complex reciprocating steam engines,
Direct drive, 2 shafts, 6 683 ihp / 4 985 Kw = 17,00 kts
Range 3 000nm at 9,00 kts
Bunker at max displacement = 457 tons (100% coal)
Complement:
324 - 422
Cost:
£0,554 million / $2,214 million
Distribution of weights at normal displacement:
Armament: 260 tons, 4,6%
Armour: 1 989 tons, 35,3%
- Belts: 1 107 tons, 19,7%
- Torpedo bulkhead: 0 tons, 0,0%
- Armament: 430 tons, 7,6%
- Armour Deck: 426 tons, 7,6%
- Conning Tower: 27 tons, 0,5%
Machinery: 1 096 tons, 19,5%
Hull, fittings & equipment: 1 847 tons, 32,8%
Fuel, ammunition & stores: 438 tons, 7,8%
Miscellaneous weights: 0 tons, 0,0%
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
4 481 lbs / 2 032 Kg = 5,2 x 12,0 " / 305 mm shells or 1,1 torpedoes
Stability (Unstable if below 1.00): 1,05
Metacentric height 2,2 ft / 0,7 m
Roll period: 15,4 seconds
Steadiness - As gun platform (Average = 50 %): 58 %
- Recoil effect (Restricted arc if above 1.00): 0,47
Seaboat quality (Average = 1.00): 1,16
Hull form characteristics:
Hull has rise forward of midbreak
Block coefficient: 0,550
Length to Beam Ratio: 5,67 : 1
'Natural speed' for length: 17,56 kts
Power going to wave formation at top speed: 50 %
Trim (Max stability = 0, Max steadiness = 100): 50
Bow angle (Positive = bow angles forward): -42,00 degrees
Stern overhang: 0,00 ft / 0,00 m
Freeboard (% = measuring location as a percentage of overall length):
- Stem: 16,47 ft / 5,02 m
- Forecastle (15%): 17,45 ft / 5,32 m
- Mid (25%): 17,45 ft / 5,32 m (8,99 ft / 2,74 m aft of break)
- Quarterdeck (14%): 8,46 ft / 2,58 m
- Stern: 9,97 ft / 3,04 m
- Average freeboard: 10,95 ft / 3,34 m
Ship tends to be wet forward
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 101,3%
- Above water (accommodation/working, high = better): 68,9%
Waterplane Area: 11 687 Square feet or 1 086 Square metres
Displacement factor (Displacement / loading): 90%
Structure weight / hull surface area: 106 lbs/sq ft or 520 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0,92
- Longitudinal: 2,23
- Overall: 1,00
Hull space for machinery, storage, compartmentation is adequate
Room for accommodation and workspaces is cramped
Dingyuan (1897)
Zhenyuan (1898)
